Note there is no wiring installed yet to the panels. Both the disconnect and controller are mounted on the wall of a closet just above the deep cycle batteries. In the above photos, a standard one-pole air conditioning disconnect is used to allow the panels to be disconnected from the controller. Solar Panel Disconnect (Left) and Tristar Solar Controllerĭisconnect and Solar Controller - Covers Closed Inverter, Starting Battery & Deep Cycle Battery Compartments The bundle of wires running down to the batteries on the right hand side includes the following:īattery voltage sense wires to solar controllerīattery temperature sense wires to solar controllerīattery current sense wires from shunt to battery monitorīattery voltage sense wires to battery monitorĪlso shown above are the 60 amp DC circuit breaker and 500A/50mV current shunt. Imp = 7.63A)ġ UL Solar 85 watt panel (Vmp = 17.9V, Imp = 4.84A)ġ Morningstar Tristar TS-45 45 amp PWM solar controllerġ Bogart Engineering Trimetric 2025-RV battery monitorĤ 6V Interstate Workaholic deep cycle batteries (total 464 amp hours)īelow are some photos of the equipment that has been installed so far. The system will consist of the following components:Ģ Kyocera 135 watt panels (Vmp = 17.7V. The system I am installing is patterned closely after the one described in HandyBob's blog (see "Blogs We Follow").
Trimetric 2025 rv battery system monitor full#
It is our intent to be able to live normally (except for running the air conditioners) and bring the batteries to a full state of charge on reasonably sunny days without plugging in to shore power or running the generator. Here is some info on the solar battery charging system that we are currently in the process of adding to the motorhome.
